Servo Hybrid PVC & PC Injection Molding Machine
HI-TECH PLASTICS ENGINEERING offers special PVC and PC Servo Hybrid Plastic Injection molding machine with well-known branded European components. As this special series is equipped with a special servo motor that is the latest technology design, so it saves energy up to 40-60%.so that is why its called servo energy saving Plastic Injection Molding Machine.
More Features:
We Provide the best services in Plastic Injection molding machine, our Technical team is fully Equipped with the best Engineers from all over Pakistan.
Our brand is the top Chinese Brand UWA who has been made JSW Plastic Injection Molding machines Since 1995.
Our Plastic Injection molding machine provide safety, easy operations and environment-friendly improvements with our energy- and space-saving
Servo Plastic injection molding machine Benefits:
1. It adopt of hydraulic unit and used to high pressure and high speed Plastic Injection Molding Machine
2. High speed response accumulator as a auxiliary power, using high sensitivity electro-hydraulic servo valve, high precision displacement sensor to realize injection speed and injection pressure closed loop control.
3. Hydraulic system quickly response, high sensitivity, low noise
4. low energy consumption and high efficiency.
Automatic lubrication system, load meter, factory fitted UPS and much wider screen combine make the Plastic injection molding machine more efficient, reliable and durable. Proportional valves of world’s famous brand are embedded in Servo hybrid PVC and PC Plastic injection molding machine which controls the action smoothly. All components of the Plastic Injection Molding Machine adopt an excellent design that strives for perfection.
HITECH PLASTICS ENGINEERING is comprehensively Provides different auxiliary equipment including Robot with IML Solution (In-Mould Labelling), Molds range, Mold Temperature Controller, Chillers, Hopper dryer, Auto Loader and Crushers of world-known brands.
| Specifications | YH80 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 30 | 32 | 35 |
| Screw L/D Ratio | L/D | 22.4 | 21 | 19.2 |
| Theoretical Injection Capacity | cm3 | 95 | 109 | 130 |
| Injection Weight (PS) | g | 87 | 99 | 118 |
| Injection Rate into Air | g/s | 73 | 83 | 99 |
| Injection Pressure | Mpa | 213 | 188 | 157 |
| Injection Stroke | mm | 135 | ||
| Screw Speed | rpm | 213 | ||
| Sphere Diameter of Nozzle | mm | SR10 | ||
| Clamping Unit | ||||
| Clamping force | KN | 800 | ||
| Max. mold opening stroke | mm | 280 | ||
| Space between tie bars | mm | 325 x 310 | ||
| Min. mould size | mm | 225 x 215 | ||
| Min. mould height | mm | 110 | ||
| Max. mould height | mm | 320 | ||
| Dia of mold location hole | mm | Φ125H7 | ||
| Ejector Stroke | mm | 80 | ||
| Ejector Force forward | KN | 45 | ||
| Ejector number | PIECE | 1 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor | KW | 9 | ||
| Heating Power | KW | 5.4 | ||
| No. of Temperature Controlled Zones | 3+1 | |||
| Oil tank cubage | (L) | 165 | ||
| Machine Dimension (LxWxH) | (m) | 3.59 x 1.11 x 1.83 | ||
| Machine weight | (t) | 2.7 | ||
| Specifications | YH98 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 35 | 38 | 40 |
| Screw L/D Ratio | L/D | 22.8 | 21 | 19.95 |
| Cylinder head volume | cm3 | 152 | 179 | 198 |
| Injection Weight (PS) | g | 138 | 163 | 181 |
| Injection Rate | g/s | 88 | 104 | 116 |
| Injection Pressure | Mpa | 219 | 186 | 168 |
| Injection Stroke | mm | 158 | ||
| Screw Speed | rpm | 224 | ||
| Sphere Diameter of Nozzle | mm | SR10 | ||
| Clamping Unit | ||||
| Clamping force | KN | 980 | ||
| Max. mold opening stroke | mm | 345 | ||
| Space between tie bars | mm | 380*370 | ||
| Min. mould size | mm | 260*260 | ||
| Min. mould height | mm | 150 | ||
| Max. mould height | mm | 380 | ||
| Dia of mold location hole | mm | Φ125H7 | ||
| Ejector Stroke | mm | 100 | ||
| Ejector Force | KN | 38 | ||
| Ejector number | PIECE | 5 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 14 | ||
| Heating capacity of screw cylinder | KW | 7.6 | ||
| Heating sections | 3+1 | |||
| Oil tank cubage | (L) | 170 | ||
| Machine Dimension (LxWxH) | (m) | 4.33*1.16*1.92 | ||
| Machine weight | (t) | 3.3 | ||
| Specifications | YH128 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 36 | 40 | 43 |
| Screw L/D Ratio | L/D | 23.3 | 21 | 19.5 |
| Cylinder head volume | cm3 | 179 | 221 | 255 |
| Injection Weight (PS) | g | 163 | 201 | 233 |
| Injection Rate | g/s | 87 | 108 | 125 |
| Injection Pressure | Mpa | 222 | 180 | 156 |
| Injection Stroke | mm | 176 | ||
| Screw Speed | rpm | 224 | ||
| Sphere Diameter of Nozzle | mm | SR10 | ||
| Clamping Unit | ||||
| Clamping force | KN | 1280 | ||
| Max. mold opening stroke | mm | 400 | ||
| Space between tie bars | mm | 410*410 | ||
| Min. mould size | mm | 300*300 | ||
| Min. mould height | mm | 150 | ||
| Max. mould height | mm | 450 | ||
| Dia of mold location hole | mm | Φ125H7 | ||
| Ejector Stroke | mm | 100 | ||
| Ejector Force | KN | 38 | ||
| Ejector number | PIECE | 5 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 14 | ||
| Heating capacity of screw cylinder | KW | 7.75 | ||
| Heating sections | 3+1 | |||
| Oil tank cubage | (L) | 200 | ||
| Machine Dimension (LxWxH) | (m) | 4.58*1.20*2.00 | ||
| Machine weight | (t) | 4 | ||
| Specifications | YH158 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 42 | 45 | 50 |
| Screw L/D Ratio | L/D | 22.5 | 21 | 18.9 |
| Cylinder head volume | cm3 | 263 | 302 | 373 |
| Injection Weight (PS) | g | 239 | 275 | 339 |
| Injection Rate | g/s | 120 | 138 | 170 |
| Injection Pressure | Mpa | 194 | 169 | 137 |
| Injection Stroke | mm | 190 | ||
| Screw Speed | rpm | 190 | ||
| Sphere Diameter of Nozzle | mm | SR10 | ||
| Clamping Unit | ||||
| Clamping force | KN | 1580 | ||
| Max. mold opening stroke | mm | 410 | ||
| Space between tie bars | mm | 440*440 | ||
| Min. mould size | mm | 310*310 | ||
| Min. mould height | mm | 150 | ||
| Max. mould height | mm | 470 | ||
| Dia of mold location hole | mm | Φ125H7 | ||
| Ejector Stroke | mm | 120 | ||
| Ejector Force | KN | 38 | ||
| Ejector number | PIECE | 5 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 17.6 | ||
| Heating capacity of screw cylinder | KW | 10.1 | ||
| Heating sections | 3+1 | |||
| Oil tank cubage | (L) | 232 | ||
| Machine Dimension (LxWxH) | (m) | 4.90*1.26*2.05 | ||
| Machine weight | (t) | 4.7 | ||
| Specifications | YH178 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 42 | 45 | 50 |
| Screw L/D Ratio | L/D | 23.8 | 22.2 | 20 |
| Cylinder head volume | cm3 | 291 | 334 | 412 |
| Injection Weight (PS) | g | 265 | 304 | 375 |
| Injection Rate | g/s | 141 | 162 | 200 |
| Injection Pressure | Mpa | 206 | 180 | 146 |
| Injection Stroke | mm | 210 | ||
| Screw Speed | rpm | 202 | ||
| Sphere Diameter of Nozzle | mm | SR10 | ||
| Clamping Unit | ||||
| Clamping force | KN | 1780 | ||
| Max. mold opening stroke | mm | 435 | ||
| Space between tie bars | mm | 470*470 | ||
| Min. mould size | mm | 325*325 | ||
| Min. mould height | mm | 180 | ||
| Max. mould height | mm | 520 | ||
| Dia of mold location hole | mm | Φ125H7 | ||
| Ejector Stroke | mm | 140 | ||
| Ejector Force | KN | 53 | ||
| Ejector number | PIECE | 5 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 18.7 | ||
| Heating capacity of screw cylinder | KW | 10.5 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 250 | ||
| Machine Dimension (LxWxH) | (m) | 5.17*1.31*2.09 | ||
| Machine weight | (t) | 5.2 | ||
| Specifications | YH208 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 45 | 50 | 55 |
| Screw L/D Ratio | L/D | 23.3 | 21 | 19.1 |
| Cylinder head volume | cm3 | 350 | 432 | 522 |
| Injection Weight (PS) | g | 318 | 393 | 475 |
| Injection Rate | g/s | 145 | 180 | 217 |
| Injection Pressure | Mpa | 210 | 170 | 141 |
| Injection Stroke | mm | 220 | ||
| Screw Speed | rpm | 180 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 2080 | ||
| Max. mold opening stroke | mm | 485 | ||
| Space between tie bars | mm | 520*520 | ||
| Min. mould size | mm | 360*360 | ||
| Min. mould height | mm | 200 | ||
| Max. mould height | mm | 550 | ||
| Dia of mold location hole | mm | Φ160H7 | ||
| Ejector Stroke | mm | 140 | ||
| Ejector Force | KN | 70 | ||
| Ejector number | PIECE | 9 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 23 | ||
| Heating capacity of screw cylinder | KW | 13.3 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 300 | ||
| Machine Dimension (LxWxH) | (m) | 5.58*1.39*2.17 | ||
| Machine weight | (t) | 6.4 | ||
| Specifications | YH268 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 55 | 60 | 64 |
| Screw L/D Ratio | L/D | 22.9 | 21 | 19.7 |
| Cylinder head volume | cm3 | 641 | 763 | 868 |
| Injection Weight (PS) | g | 583 | 694 | 790 |
| Injection Rate | g/s | 190 | 226 | 257 |
| Injection Pressure | Mpa | 193 | 162.4 | 143 |
| Injection Stroke | mm | 270 | ||
| Screw Speed | rpm | 189 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 2680 | ||
| Max. mold opening stroke | mm | 550 | ||
| Space between tie bars | mm | 580*580 | ||
| Min. mould size | mm | 420*420 | ||
| Min. mould height | mm | 220 | ||
| Max. mould height | mm | 580 | ||
| Dia of mold location hole | mm | Φ160H7 | ||
| Ejector Stroke | mm | 150 | ||
| Ejector Force | KN | 70 | ||
| Ejector number | PIECE | 9 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 23 | ||
| Heating capacity of screw cylinder | KW | 16.9 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 400 | ||
| Machine Dimension (LxWxH) | (m) | 6.16*1.47*2.26 | ||
| Machine weight | (t) | 7.5 | ||
| Specifications | YH308 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 55 | 60 | 64 |
| Screw L/D Ratio | L/D | 22.9 | 21 | 19.7 |
| Cylinder head volume | cm3 | 648 | 771 | 878 |
| Injection Weight (PS) | g | 590 | 702 | 799 |
| Injection Rate | g/s | 211 | 251 | 285 |
| Injection Pressure | Mpa | 219 | 184 | 162 |
| Injection Stroke | mm | 273 | ||
| Screw Speed | rpm | 238 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 3080 | ||
| Max. mold opening stroke | mm | 600 | ||
| Space between tie bars | mm | 680*630 | ||
| Min. mould size | mm | 475*440 | ||
| Min. mould height | mm | 230 | ||
| Max. mould height | mm | 630 | ||
| Dia of mold location hole | mm | Φ160H7 | ||
| Ejector Stroke | mm | 170 | ||
| Ejector Force | KN | 70 | ||
| Ejector number | PIECE | 13 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 40.9 | ||
| Heating capacity of screw cylinder | KW | 19.6 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 600 | ||
| Machine Dimension (LxWxH) | (m) | 6.32*2.03*2.16 | ||
| Machine weight | (t) | 11 | ||
| Specifications | YH358 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 60 | 65 | 70 |
| Screw L/D Ratio | L/D | 22.8 | 21 | 19.5 |
| Cylinder head volume | cm3 | 814 | 955 | 1108 |
| Injection Weight (PS) | g | 741 | 869 | 1008 |
| Injection Rate | g/s | 245 | 287 | 333 |
| Injection Pressure | Mpa | 198 | 169 | 146 |
| Injection Stroke | mm | 288 | ||
| Screw Speed | rpm | 167 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 3580 | ||
| Max. mold opening stroke | mm | 660 | ||
| Space between tie bars | mm | 730*680 | ||
| Min. mould size | mm | 510*475 | ||
| Min. mould height | mm | 250 | ||
| Max. mould height | mm | 700 | ||
| Dia of mold location hole | mm | Φ160H7 | ||
| Ejector Stroke | mm | 180 | ||
| Ejector Force | KN | 70 | ||
| Ejector number | PIECE | 13 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 40.9 | ||
| Heating capacity of screw cylinder | KW | 18.6 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 640 | ||
| Machine Dimension (LxWxH) | (m) | 6.64*2.09*2.30 | ||
| Machine weight | (t) | 12.7 | ||
| Specifications | YH408 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 70 | 75 | 80 |
| Screw L/D Ratio | L/D | 22.5 | 21 | 19.7 |
| Cylinder head volume | cm3 | 1335 | 1532 | 1743 |
| Injection Weight (PS) | g | 1215 | 1394 | 1586 |
| Injection Rate | g/s | 305 | 350 | 398 |
| Injection Pressure | Mpa | 199 | 173 | 152 |
| Injection Stroke | mm | 347 | ||
| Screw Speed | rpm | 179 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 4080 | ||
| Max. mold opening stroke | mm | 730 | ||
| Space between tie bars | mm | 780*730 | ||
| Min. mould size | mm | 545*510 | ||
| Min. mould height | mm | 250 | ||
| Max. mould height | mm | 780 | ||
| Dia of mold location hole | mm | Φ160H7 | ||
| Ejector Stroke | mm | 200 | ||
| Ejector Force | KN | 110 | ||
| Ejector number | PIECE | 13 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 50.7 | ||
| Heating capacity of screw cylinder | KW | 26 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 720 | ||
| Machine Dimension (LxWxH) | (m) | 7.48*2.17*2.38 | ||
| Machine weight | (t) | 15.2 | ||
| Specifications | YH488 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 75 | 80 | 85 |
| Screw L/D Ratio | L/D | 22.4 | 21 | 10.8 |
| Cylinder head volume | cm3 | 1722 | 1959 | 2212 |
| Injection Weight (PS) | g | 1567 | 1783 | 2013 |
| Injection Rate | g/s | 397 | 452 | 510 |
| Injection Pressure | Mpa | 196 | 172 | 152 |
| Injection Stroke | mm | 390 | ||
| Screw Speed | rpm | 178 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 4880 | ||
| Max. mold opening stroke | mm | 780 | ||
| Space between tie bars | mm | 830*780 | ||
| Min. mould size | mm | 580*545 | ||
| Min. mould height | mm | 320 | ||
| Max. mould height | mm | 800 | ||
| Dia of mold location hole | mm | Φ200H7 | ||
| Ejector Stroke | mm | 220 | ||
| Ejector Force | KN | 110 | ||
| Ejector number | PIECE | 13 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 26.7+26.7 | ||
| Heating capacity of screw cylinder | KW | 31 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 850 | ||
| Machine Dimension (LxWxH) | (m) | 8.11*2.18*2.58 | ||
| Machine weight | (t) | 18.9 | ||
| Specifications | YH568 | |||
|---|---|---|---|---|
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 80 | 85 | 90 |
| Screw L/D Ratio | L/D | 22.3 | 21 | 19.8 |
| Cylinder head volume | cm3 | 2185 | 2467 | 2766 |
| Injection Weight (PS) | g | 1989 | 2245 | 2517 |
| Injection Rate | g/s | 412 | 465 | 521 |
| Injection Pressure | Mpa | 189 | 167 | 149 |
| Injection Stroke | mm | 435 | ||
| Screw Speed | rpm | 150 | ||
| Sphere Diameter of Nozzle | mm | SR15 | ||
| Clamping Unit | ||||
| Clamping force | KN | 5680 | ||
| Max. mold opening stroke | mm | 820 | ||
| Space between tie bars | mm | 880*830 | ||
| Min. mould size | mm | 615*580 | ||
| Min. mould height | mm | 350 | ||
| Max. mould height | mm | 850 | ||
| Dia of mold location hole | mm | Φ200H7 | ||
| Ejector Stroke | mm | 240 | ||
| Ejector Force | KN | 158 | ||
| Ejector number | PIECE | 17 | ||
| Others | ||||
| Rated pressure of oil pump | Mpa | 16 | ||
| Pump motor power | KW | 26.7+26.7 | ||
| Heating capacity of screw cylinder | KW | 34.6 | ||
| Heating sections | 4+1 | |||
| Oil tank cubage | (L) | 950 | ||
| Machine Dimension (LxWxH) | (m) | 8.81*2.26*2.77 | ||
| Machine weight | (t) | 21.7 | ||
| Specifications | YH658 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 85 | 90 | 95 | 100 |
| Screw L/D Ratio | L/D | 22.2 | 21 | 19.9 | 18.9 |
| Cylinder head volume | cm3 | 2637 | 2957 | 3294 | 3650 |
| Injection Weight (PS) | g | 2400 | 2691 | 2998 | 3322 |
| Injection Rate | g/s | 527 | 591 | 658 | 729 |
| Injection Pressure | Mpa | 202 | 180 | 161 | 146 |
| Injection Stroke | mm | 465 | |||
| Screw Speed | rpm | 143 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 6580 | |||
| Max. mold opening stroke | mm | 930 | |||
| Space between tie bars | mm | 960*880 | |||
| Min. mould size | mm | 670*615 | |||
| Min. mould height | mm | 350 | |||
| Max. mould height | mm | 900 | |||
| Dia of mold location hole | mm | Φ200H7 | |||
| Ejector Stroke | mm | 250 | |||
| Ejector Force | KN | 158 | |||
| Ejector number | PIECE | 21 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 40.9+40.9 | |||
| Heating capacity of screw cylinder | KW | 41 | |||
| Heating sections | 5+1 | ||||
| Oil tank cubage | (L) | 1000 | |||
| Machine Dimension (LxWxH) | (m) | 9.80*2.38*2.35 | |||
| Machine weight | (t) | 27 | |||
| Specifications | YH788 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 90 | 95 | 105 | 110 |
| Screw L/D Ratio | L/D | 23.2 | 22 | 19.9 | 18.9 |
| Cylinder head volume | cm3 | 3052 | 3401 | 4154 | 4559 |
| Injection Weight (PS) | g | 2777 | 3095 | 3780 | 4149 |
| Injection Rate | g/s | 608 | 677 | 827 | 908 |
| Injection Pressure | Mpa | 197 | 176 | 144 | 132 |
| Injection Stroke | mm | 480 | |||
| Screw Speed | rpm | 129 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 7880 | |||
| Max. mold opening stroke | mm | 1030 | |||
| Space between tie bars | mm | 1060*980 | |||
| Min. mould size | mm | 740*685 | |||
| Min. mould height | mm | 400 | |||
| Max. mould height | mm | 1000 | |||
| Dia of mold location hole | mm | Φ200H7 | |||
| Ejector Stroke | mm | 280 | |||
| Ejector Force | KN | 215 | |||
| Ejector number | PIECE | 21 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 40.9+50.7 | |||
| Heating capacity of screw cylinder | KW | 45.1 | |||
| Heating sections | 5+1 | ||||
| Oil tank cubage | (L) | 1100 | |||
| Machine Dimension (LxWxH) | (m) | 10.60*2.60*3.22 | |||
| Machine weight | (t) | 37 | |||
| Specifications | YH968 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 90 | 100 | 110 | 120 |
| Screw L/D Ratio | L/D | 24.4 | 22 | 20 | 18.3 |
| Cylinder head volume | cm3 | 3179 | 3925 | 4749 | 5652 |
| Injection Weight (PS) | g | 2893 | 3572 | 4322 | 5143 |
| Injection Rate | g/s | 609 | 752 | 910 | 1083 |
| Injection Pressure | Mpa | 218 | 176 | 146 | 123 |
| Injection Stroke | mm | 500 | |||
| Screw Speed | rpm | 100 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 9680 | |||
| Max. mold opening stroke | mm | 1150 | |||
| Space between tie bars | mm | 1160*1080 | |||
| Min. mould size | mm | 810*755 | |||
| Min. mould height | mm | 400 | |||
| Max. mould height | mm | 1100 | |||
| Dia of mold location hole | mm | Φ200H7 | |||
| Ejector Stroke | mm | 300 | |||
| Ejector Force | KN | 215 | |||
| Ejector number | PIECE | 21 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 50.7+50.7 | |||
| Heating capacity of screw cylinder | KW | 55.2 | |||
| Heating sections | 5+1 | ||||
| Oil tank cubage | (L) | 1250 | |||
| Machine Dimension (LxWxH) | (m) | 11.60*2.78*3.40 | |||
| Machine weight | (t) | 47 | |||
| Specifications | YH1180 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 100 | 110 | 120 | 130 |
| Screw L/D Ratio | L/D | 24.2 | 22 | 20.2 | 18.6 |
| Cylinder head volume | cm3 | 4318 | 5224 | 6217 | 7297 |
| Injection Weight (PS) | g | 3929 | 4754 | 5658 | 6640 |
| Injection Rate | g/s | 754 | 912 | 1086 | 1274 |
| Injection Pressure | Mpa | 211 | 175 | 147 | 125 |
| Injection Stroke | mm | 550 | |||
| Screw Speed | rpm | 110 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 11800 | |||
| Max. mold opening stroke | mm | 1250 | |||
| Space between tie bars | mm | 1260*1180 | |||
| Min. mould size | mm | 880*825 | |||
| Min. mould height | mm | 550 | |||
| Max. mould height | mm | 1250 | |||
| Dia of mold location hole | mm | Φ250H7 | |||
| Ejector Stroke | mm | 350 | |||
| Ejector Force | KN | 269 | |||
| Ejector number | PIECE | 29 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Servo motor power | KW | 40.9+40.9+40.9 | |||
| Heating capacity of screw cylinder | KW | 65.5 | |||
| Heating sections | 5+1 | ||||
| Oil tank cubage | (L) | 1450 | |||
| Machine Dimension (LxWxH) | m | 12.5*2.85*3.3 | |||
| Machine weight | (t) | 62 | |||
| Specifications | YH1380 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 110 | 120 | 130 | 140 |
| Screw L/D Ratio | L/D | 24 | 22 | 20.3 | 18.8 |
| Cylinder head volume | cm3 | 5699 | 6782 | 7960 | 9232 |
| Injection Weight (PS) | g | 5186 | 6172 | 7244 | 8401 |
| Injection Rate | g/s | 938 | 1116 | 1310 | 1519 |
| Injection Pressure | Mpa | 198 | 166 | 142 | 122 |
| Injection Stroke | mm | 600 | |||
| Screw Speed | rpm | 103 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 13800 | |||
| Max. mold opening stroke | mm | 1420 | |||
| Space between tie bars | mm | 1360*1280 | |||
| Min. mould size | mm | 950*895 | |||
| Min. mould height | mm | 650 | |||
| Max. mould height | mm | 1400 | |||
| Dia of mold location hole | mm | Φ315H7 | |||
| Ejector Stroke | mm | 350 | |||
| Ejector Force | KN | 269 | |||
| Ejector number | PIECE | 29 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 40.9+50.7+50.7 | |||
| Heating capacity of screw cylinder | KW | 77.5 | |||
| Heating sections | 5+1 | ||||
| Oil tank cubage | (L) | 1700 | |||
| Machine Dimension (LxWxH) | m | 14*2.95*3.38 | |||
| Machine weight | (t) | 75 | |||
| Specifications | YH1680 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 130 | 140 | 150 | 160 |
| Screw L/D Ratio | L/D | 23.7 | 22 | 20.4 | 19.3 |
| Cylinder head volume | cm3 | 9154 | 10616 | 12187 | 13866 |
| Injection Weight (PS) | g | 8330 | 9661 | 11090 | 12618 |
| Injection Rate | g/s | 1148 | 1332 | 1529 | 1739 |
| Injection Pressure | Mpa | 185 | 159 | 139 | 122 |
| Injection Stroke | mm | 690 | |||
| Screw Speed | rpm | 90 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 16800 | |||
| Max. mold opening stroke | mm | 1600 | |||
| Space between tie bars | mm | 1560*1480 | |||
| Min. mould size | mm | 1090*1035 | |||
| Min. mould height | mm | 700 | |||
| Max. mould height | mm | 1600 | |||
| Dia of mold location hole | mm | Φ315H7 | |||
| Ejector Stroke | mm | 400 | |||
| Ejector Force | KN | 350 | |||
| Ejector number | PIECE | 25 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 40.9+40.9+40.9+40.9 | |||
| Heating capacity of screw cylinder | KW | 98.4 | |||
| Heating sections | 6+1 | ||||
| Oil tank cubage | (L) | 2500 | |||
| Machine Dimension (LxWxH) | m | 15.8*3.3*3.6 | |||
| Machine weight | (t) | 105 | |||
| Specifications | YH2280 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 150 | 160 | 170 | 180 |
| Screw L/D Ratio | L/D | 23.5 | 22 | 20.7 | 19.6 |
| Cylinder head volume | cm3 | 14130 | 16077 | 18149 | 20347 |
| Injection Weight (PS) | g | 12858 | 14630 | 16516 | 18516 |
| Injection Rate | g/s | 1533 | 1744 | 1969 | 2208 |
| Injection Pressure | Mpa | 173 | 152 | 135 | 120 |
| Injection Stroke | mm | 800 | |||
| Screw Speed | rpm | 100 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 22800 | |||
| Max. mold opening stroke | mm | 1900 | |||
| Space between tie bars | mm | 1820*1620 | |||
| Min. mould size | mm | 1275*1135 | |||
| Min. mould height | mm | 750 | |||
| Max. mould height | mm | 1700 | |||
| Dia of mold location hole | mm | Φ315H7 | |||
| Ejector Stroke | mm | 400 | |||
| Ejector Force | KN | 430 | |||
| Ejector number | PIECE | 29 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 50.7+50.7+50.7+50.7 | |||
| Heating capacity of screw cylinder | KW | 133.7 | |||
| Heating sections | 6+2 | ||||
| Oil tank cubage | (L) | 2000 | |||
| Machine Dimension (LxWxH) | m | 16.80*4.70*5.30 | |||
| Machine weight | (t) | 145 | |||
| Specifications | YH2880 | ||||
|---|---|---|---|---|---|
| Injection Unit | A | B | C | D | |
| Screw Diameter | mm | 190 | 200 | 210 | 220 |
| Screw L/D Ratio | L/D | 23.2 | 22 | 21 | 20 |
| Cylinder head volume | cm3 | 32561 | 36079 | 39777 | 43655 |
| Injection Weight (PS) | g | 29630 | 32832 | 36197 | 39726 |
| Injection Rate | g/s | 1994 | 2210 | 2436 | 2674 |
| Injection Pressure | Mpa | 166 | 150 | 136 | 124 |
| Injection Stroke | mm | 1149 | |||
| Screw Speed | rpm | 63 | |||
| Sphere Diameter of Nozzle | mm | SR20 | |||
| Clamping Unit | |||||
| Clamping force | KN | 28800 | |||
| Max. mold opening stroke | mm | 2050 | |||
| Space between tie bars | mm | 2060*1780 | |||
| Min. mould size | mm | 1440*1240 | |||
| Min. mould height | mm | 1000 | |||
| Max. mould height | mm | 1900 | |||
| Dia of mold location hole | mm | Φ315H7 | |||
| Ejector Stroke | mm | 450 | |||
| Ejector Force | KN | 430 | |||
| Ejector number | PIECE | 29 | |||
| Others | |||||
| Rated pressure of oil pump | Mpa | 17.5 | |||
| Pump motor power | KW | 50.7+50.7+50.7+50.7+50.7 | |||
| Heating capacity of screw cylinder | KW | 215 | |||
| Heating sections | 6+2 | ||||
| Oil tank cubage | (L) | 3500 | |||
| Machine Dimension (LxWxH) | m | 19.80*4.80*5.50 | |||
| Machine weight | (t) | 197 | |||
Applications
