High Speed Plastic Basket Series Injection Molding Machine
Hi TECH Machinery General Trading L.L.C introduce the Plastic Basket dedicated Plastic Molding Machine which is specially designed for producing disposable plastic fruit basket. UWA Tong young high-speed plastic basket series injection molding machine has capability to provide higher injection rate as compared to an ordinary machine due to its large injection volume. Manufacturer can produce plastic baskets that has width up to 880mm and length up to 880mm. Raw material for manufacturing plastic baskets can be PP, PC, PVC, ABS, LDPE, HDPE and so on. Accurate injection control and injection speed is achieved by fast and precise injection technology. Injection molding machine provides high stability and responsiveness. This special series of UWA Tong young is suitable for the processing of recycled plastic with low cost.
Hi TECH Machinery General Trading L.L.C is comprehensively Provides different auxiliary equipment including Robot with IML Solution (in-mold labeling), Molds range, Mold Temperature Controller, Chillers, Hopper dryer, Auto Loader and Crushers of world-known brands.
| Specifications | TWX3580 | |
|---|---|---|
| Injection Unit | D | |
| Screw Diameter | mm | 80 |
| Screw L/D Ratio | L/D | 21 |
| Cylinder head volume | cm3 | 1608 |
| Injection Weight | g | 1463 |
| Injection Rate (PS) | g/s | 512 |
| Injection Pressure | MPa | 120 |
| Injection Stroke | mm | 320 |
| Screw Speed | rpm | 190 |
| Sphere Diameter of Nozzle | mm | SR15 |
| Clamping Unit | ||
| Clamping force | KN | 3580 |
| Max. mold opening stroke | mm | 660 |
| Space between tie bars | mm | 660*660 |
| Min. mould size | mm | 460*460 |
| Min. mould height | mm | 250 |
| Max. mould height | mm | 700 |
| Dia of mold location hole | mm | 160H7 |
| Ejector Stroke | mm | 160 |
| Ejector Force | KN | 70 |
| Ejector number | PIECE | 13 |
| Others | ||
| Rated pressure of oil pump | MPa | 16 |
| Pump motor power | KW | 37 |
| Servo motor power | KW | 40.9 |
| Heating capacity of screw cylinder | KW | 30 |
| Heating sections | 5+1 | |
| Oil tank cubage | (L) | 655 |
| Machine Dimension (LxWxH) | (m) | 6.85*1.72*2.30 |
| Machine weight | (t) | 11.4 |
| Specifications | TWX4080 | |
|---|---|---|
| Injection Unit | D | |
| Screw Diameter | mm | 90 |
| Screw L/D Ratio | L/D | 21 |
| Cylinder head volume | cm3 | 2353 |
| Injection Weight | g | 2141 |
| Injection Rate (PS) | g/s | 637 |
| Injection Pressure | MPa | 120 |
| Injection Stroke | mm | 370 |
| Screw Speed | rpm | 190 |
| Sphere Diameter of Nozzle | mm | SR15 |
| Clamping Unit | ||
| Clamping force | KN | 4080 |
| Max. mold opening stroke | mm | 720 |
| Space between tie bars | mm | 720*720 |
| Min. mould size | mm | 500*500 |
| Min. mould height | mm | 250 |
| Max. mould height | mm | 780 |
| Dia of mold location hole | mm | 160H7 |
| Ejector Stroke | mm | 180 |
| Ejector Force | KN | 110 |
| Ejector number | PIECE | 13 |
| Others | ||
| Rated pressure of oil pump | MPa | 16 |
| Pump motor power | KW | 45 |
| Servo motor power | KW | 50.7 |
| Heating capacity of screw cylinder | KW | 40 |
| Heating sections | 5+1 | |
| Oil tank cubage | (L) | 700 |
| Machine Dimension (LxWxH) | (m) | 7.65*2.00*2.50 |
| Machine weight | (t) | 15.4 |
| Specifications | TWX4880 | |
|---|---|---|
| Injection Unit | D | |
| Screw Diameter | mm | 95 |
| Screw L/D Ratio | L/D | 21 |
| Cylinder head volume | cm3 | 2919 |
| Injection Weight | g | 2656 |
| Injection Rate (PS) | g/s | 678 |
| Injection Pressure | MPa | 119 |
| Injection Stroke | mm | 412 |
| Screw Speed | rpm | 170 |
| Sphere Diameter of Nozzle | mm | SR15 |
| Clamping Unit | ||
| Clamping force | KN | 4880 |
| Max. mold opening stroke | mm | 780 |
| Space between tie bars | mm | 780*780 |
| Min. mould size | mm | 545*545 |
| Min. mould height | mm | 320 |
| Max. mould height | mm | 800 |
| Dia of mold location hole | mm | 200H7 |
| Ejector Stroke | mm | 200 |
| Ejector Force | KN | 110 |
| Ejector number | PIECE | 13 |
| Others | ||
| Rated pressure of oil pump | MPa | 16 |
| Pump motor power | KW | 55 |
| Servo motor power | KW | 26.7+26.7 |
| Heating capacity of screw cylinder | KW | 48 |
| Heating sections | 5+1 | |
| Oil tank cubage | (L) | 850 |
| Machine Dimension (LxWxH) | (m) | 8.20*2.04*2.70 |
| Machine weight | (t) | 18.2 |
| Specifications | TWX5680 | |
|---|---|---|
| Injection Unit | D | |
| Screw Diameter | mm | 100 |
| Screw L/D Ratio | L/D | 21 |
| Cylinder head volume | cm3 | 3533 |
| Injection Weight | g | 3215 |
| Injection Rate (PS) | g/s | 714 |
| Injection Pressure | MPa | 118 |
| Injection Stroke | mm | 450 |
| Screw Speed | rpm | 140 |
| Sphere Diameter of Nozzle | mm | SR15 |
| Clamping Unit | ||
| Clamping force | KN | 5680 |
| Max. mold opening stroke | mm | 820 |
| Space between tie bars | mm | 820*820 |
| Min. mould size | mm | 570*570 |
| Min. mould height | mm | 350 |
| Max. mould height | mm | 820 |
| Dia of mold location hole | mm | 200H7 |
| Ejector Stroke | mm | 230 |
| Ejector Force | KN | 158 |
| Ejector number | PIECE | 17 |
| Others | ||
| Rated pressure of oil pump | MPa | 16 |
| Pump motor power | KW | 55 |
| Servo motor power | KW | 26.7+26.7 |
| Heating capacity of screw cylinder | KW | 56 |
| Heating sections | 5+1 | |
| Oil tank cubage | (L) | 950 |
| Machine Dimension (LxWxH) | (m) | 8.95*2.04*2.90 |
| Machine weight | (t) | 19.8 |
| Specifications | TWX6580 | |
|---|---|---|
| Injection Unit | D | |
| Screw Diameter | mm | 110 |
| Screw L/D Ratio | L/D | 20 |
| Cylinder head volume | cm3 | 4277 |
| Injection Weight | g | 3891 |
| Injection Rate (PS) | g/s | 864 |
| Injection Pressure | MPa | 118 |
| Injection Stroke | mm | 450 |
| Screw Speed | rpm | 130 |
| Sphere Diameter of Nozzle | mm | SR15 |
| Clamping Unit | ||
| Clamping force | KN | 6580 |
| Max. mold opening stroke | mm | 900 |
| Space between tie bars | mm | 880*880 |
| Min. mould size | mm | 615*615 |
| Min. mould height | mm | 350 |
| Max. mould height | mm | 900 |
| Dia of mold location hole | mm | 250H7 |
| Ejector Stroke | mm | 250 |
| Ejector Force | KN | 158 |
| Ejector number | PIECE | 17 |
| Others | ||
| Rated pressure of oil pump | MPa | 16 |
| Pump motor power | KW | 37+37 |
| Servo motor power | KW | 40.9+40.9 |
| Heating capacity of screw cylinder | KW | 62 |
| Heating sections | 5+1 | |
| Oil tank cubage | (L) | 1200 |
| Machine Dimension (LxWxH) | (m) | 9.60*2.35*2.90 |
| Machine weight | (t) | 26 |
