HGB Gravimetric Blenders
• Suitable for use in plastic injection, extrusion or hollow molding process where multiple raw materials are required to be mixed by weight.
• Adopts the Austrian B & R control system and an adaptive algorithm
• Implement high-precision AD conversion module.
| Specifications | HGB-1 | |||
| -4 | -3 | -2 | ||
| Group Number | 4 | 3 | 2 | |
| Max. Output | kg/hr | 50 | 60 | 130 |
| Knife metering value | set | 4 | 3 | 2 |
| Trace metering value | set | — | — | — |
| Max. Throughput | kg | 1 | ||
| Mixing Motor Power | W | 90 | ||
| Storage Hopper | L | 12 | ||
| Weighing bucket capacity | L | 2 | ||
| Mixing Warehouse capacity | L | 8 | ||
| The biggest batch quantity | Hr | 50 | 60 | 130 |
| Dimensions | mm | 1150*800*650 | ||
| Specifications | HGB-2 | |||||
| -6 | -5 | -4 | -3 | -2 | ||
| Group Number | 6 | 5 | 4 | 3 | 2 | |
| Max. Output | kg/hr | 100 | 120 | 160 | 180 | 360 |
| Knife metering value | set | 4 | 4 | 4 | 3 | 2 |
| Trace metering value | set | 2 | 1 | 0 | 0 | 0 |
| Max. Throughput | kg | 2 | ||||
| Mixing Motor Power | W | 90 | ||||
| Storage Hopper | L | 40 | ||||
| Weighing bucket capacity | L | 8 | ||||
| Mixing Warehouse capacity | L | 18 | ||||
| The biggest batch quantity | Hr | 50 | 60 | 80 | 90 | 180 |
| Dimensions | mm | 1650*900*1300 | 1650*900*1050 | 1650*900*820 | ||
| Specifications | HGB-5 | |||||
| -6 | -5 | -4 | -3 | -2 | ||
| Group Number | 6 | 5 | 4 | 3 | 2 | |
| Max. Output | kg/hr | 250 | 300 | 400 | 450 | 900 |
| Knife metering value | set | 4 | 4 | 4 | 3 | 2 |
| Trace metering value | set | 0 | 0 | 0 | 0 | 0 |
| Max. Throughput | kg | 5 | ||||
| Mixing Motor Power | W | 200 | ||||
| Storage Hopper | L | 48 | ||||
| Weighing bucket capacity | L | 12 | ||||
| Mixing Warehouse capacity | L | 25 | ||||
| The biggest batch quantity | Hr | 50 | 60 | 80 | 90 | 180 |
| Dimensions | mm | 1850*1000*1500 | 1850*1000*1250 | 1850*1000*1000 | ||
| Specifications | HGB-10 | |||||
| -6 | -5 | -4 | -3 | -2 | ||
| Group Number | 6 | 5 | 4 | 3 | 2 | |
| Max. Output | kg/hr | 670 | 700 | 900 | 1000 | 1800 |
| Knife metering value | set | 6 | 5 | 4 | 3 | 2 |
| Trace metering value | set | 0 | 0 | 0 | 0 | 0 |
| Max. Throughput | kg | 10 | ||||
| Mixing Motor Power | W | 370 | ||||
| Storage Hopper | L | 100 | ||||
| Weighing bucket capacity | L | 32 | ||||
| Mixing Warehouse capacity | L | 60 | ||||
| The biggest batch quantity | Hr | 60 | 70 | 90 | 100 | 180 |
| Dimensions | mm | 2400*1200*1200 | ||||
| Specifications | HGB-25 | |||||
| -6 | -5 | -4 | -3 | -2 | ||
| Group Number | 6 | 5 | 4 | 3 | 2 | |
| Max. Output | kg/hr | 1500 | 1750 | 2000 | 2500 | 4000 |
| Knife metering value | set | 6 | 5 | 4 | 3 | 2 |
| Trace metering value | set | 0 | 0 | 0 | 0 | 0 |
| Max. Throughput | kg | 25 | ||||
| Mixing Motor Power | W | 750 | ||||
| Storage Hopper | L | 150 | ||||
| Weighing bucket capacity | L | 65 | ||||
| Mixing Warehouse capacity | L | 120 | ||||
| The biggest batch quantity | Hr | 60 | 70 | 80 | 100 | 160 |
| Dimensions | mm | 3000*1600*1600 | ||||
