HCD Box Dryer
- Suitable for drying all kinds of polymer materials, especially for small and diverse raw materials or test molds.
- Capable of drying different materials at the same time.
- Can also be used for electronics, motors, electroplating and baking paint
- Reducing power loss and consistent temperature is maintained by high temperature sealed door.
| Specifications | HCD-5 | |
|---|---|---|
| Heat power | KW | 4 |
| Blower Power | KW | 0.37 |
| Material loading capacity | kg | 50 |
| Number of trays | 5 | |
| Weight | kg | 128 |
| Internal Dimension | mm | 660*600*550 |
| External Dimension | mm | 1200*800*620 |
| Specifications | HCD-9 | |
|---|---|---|
| Heat power | KW | 4.5 |
| Blower Power | KW | 0.37 |
| Material loading capacity | kg | 100 |
| Number of trays | 9 | |
| Weight | kg | 158 |
| Internal Dimension | mm | 900*600*550 |
| External Dimension | mm | 1440*800*620 |
| Specifications | HCD-20 | |
|---|---|---|
| Heat power | KW | 9 |
| Blower Power | KW | 1.5 |
| Material loading capacity | kg | 200 |
| Number of trays | 20 | |
| Weight | kg | 390 |
| Internal Dimension | mm | 1000*900*800 |
| External Dimension | mm | 1700*1210*870 |
