Dry feeding optional accessories
A variety of optional accessories suitable for raw material protection of dryers and feeders, environmental improvement, performance expansion and structural extension.
These optional accessories include Exhaust air filter, Fan inlet filter, Magnetic base, Magnetic stand, Moving header, Hot air recycler, Above ground bracket and Suction box.
| Exhaust air filter | |
| Type | Suitable type |
| EAF-12 | HHD-12E |
| EAF-25 | HHD-25E |
| EAF-50 | HHD-50E-75E |
| EAF-100 | HHD-100E-150E |
| EAF-200 | HHD-200E-1000E |
| Fan Inlet Filter | ||
| Type | Suitable type | Filter Diameter (mm) |
| FIF-12 | HHD-12E | 100 |
| FIF-25 | HHD-25E | 135 |
| FIF-50 | HHD-50E-75E | 135 |
| FIF-100 | HHD-100E-150E | 185 |
| FIF-200S | HHD-200E | 185 |
| FIF-300 | HHD-300E-600E | 220 |
| FIF-800 | HHD-800E-1000E | 220 |
| Magnetic Base | ||
| Type | Suitable type | No. of Magnetic Tubes |
| MB-12 | HHD-12E | 3 |
| MB-25 | HHD-25E | 3 |
| MB-50 | HHD-50E-75E | 3 |
| MB-100 | HHD-100E-150E | 3 |
| MB-200 | HHD-200E | 5 |
| MB-300 | HHD-300E | 5 |
| MB-400 | HHD-400E | 5 |
| MB-600 | HHD-600E-800E | 5 |
| MB-1000 | HHD-1000E | 5 |
| Magnetic Frame | ||
| Type | Suitable type | No. of Magnetic Tubes |
| MF-5 | HHD-12E | 5 |
| MF-7 | HHD-25E-75E | 7 |
| MF-9 | HHD-100E-400E | 9 |
| MF-11 | HHD-600E-1000E | 11 |
| Mobile Collection Bin | ||
| Type | Loading Capacity (kg) | Dimensions HxWxD (mm) |
| MCBY-25 | 25 | 381*690 |
| MCBY-50 | 50 | 381*900 |
| MCBX-50 | 50 | 500*500*880 |
| MCBX-100 | 100 | 670*670*925 |
| MCBX-150 | 150 | 815*815*1025 |
| MCBX-200 | 200 | 815*815*1140 |
| MCBX-300 | 300 | 915*915*1270 |
| MCBX-400 | 400 | 1115*1115*1270 |
| Hot Air Recycling | ||
| Type | Suitable type | Filter Diameter (mm) |
| HAR-12 | HHD-12E | 100 |
| HAR-25 | HHD-25E | 135 |
| HAR-50 | HHD-50E-75E | 135 |
| HAR-100 | HHD-100E-150E | 185 |
| HAR-200S | HHD-200E | 185 |
| HAR-300 | HHD-300E-600E | 220 |
| HAR-800 | HHD-800E-1000E | 220 |
| Ground Frame | ||
| Type | Suitable type | Dimensions HxWxD (mm) |
| GF-50 | HHD-12E-75E | 537*850*520 |
| GF-100 | HHD-100E-150E | 587*970*720 |
| GF-200 | HHD-200E | 652*1240*840 |
| GF-300 | HHD-300E | 775*1000*1000 |
| GF-400 | HHD-400E | 1150*1200*1200 |
| GF-600 | HHD-600E-800E | 1255*1300*1300 |
| GF-1000 | HHD-1000E | 1635*1300*1300 |
| Suction Box | ||
| Type | Suitable type | Pipe Diameter (inch) |
| HSB-50-38S | HHD Series | 1.5″ |
| HSB-50-38D | HHD Series | 1.5″x2 |
| HSB-50-50S | HHD Series | 2″ |
| HSB-50-50D | HHD Series | 2″x2 |
